Cell Shades
Cordless
PRODUCT SPECIFICATIONS
| Fabric | Translucent or Room Darkening spun lace, non woven fabric. 100% Polyester. |
| Head Rail | 1 1/2” High x 1 3/4” Deep extruded aluminum, with PVC end caps. Depth with installation bracket is 2”. |
| Bottom Rail | 1/2” High x 1 5/8” deep extruded aluminum with PVC end caps. |
| Cordless Modules | Cordless modules are constructed with clear PVC body. Lift cord is wound inside the module. Steel spring provides tension to pull the shade up. A steel d-rod link all modules together inside the head rail. |
| Lift Cords | Shall be braided polyester and of sufficient length to control the raising and lowering of the shade. Outside diameter is 0.9mm. |
| Weights | : 100% Steel, Zinc plated with double sided tape. |
| Handle | 100% PVC |
| Installation Brackets: | Constructed of cold rolled steel. Zinc plated. Hex head screws are included. Intermediate brackets spaced no wider than 36” apart. |
| Sizes | Outside mounted window coverings will be made to exact ordered measurements. Inside mounted horizontal blinds will have ½” deducted at the factory from width. See Product Limits. |
PRODUCT LIMITS
| Controls (Manual) | Min. Width | Max. Width | Min. Drop | *Max. Drop |
|---|---|---|---|---|
| Cordless | 12" | 84" | 5" | 82" |
Maximum Sq. Footage *48 sq. ft. under warranty
*Exceptions available upon request
top-down/bottom-up
PRODUCT SPECIFICATIONS
| Fabric | Translucent or Room Darkening spun lace, non woven fabric. 100% Polyester |
| Top Head Rail | 1 1/2” high x 1 3/4” deep extruded aluminum with PVC end caps. Depth with installation bracket is 2”. |
| Mid Head Rail | 3/4” high x 1 5/8” deep extruded aluminum with PVC end caps. |
| Bottom Rail | 1/2” high x 1 5/8” deep extruded aluminum with PVC end caps. |
| Cord Lock | Cord lock shall be secured to the head rail channel. Lock body shall be constructed of clear polycarbonate,. Floating gear and pins locks shall e made of brass. Cord lock to be of crash-proof design. |
| Cord Cleat | Cleat is made of clear 100% PVC. |
| Lift Cords | Shall be braided polyester and of sufficient length to control the raising and lowering of the shade. Outside diameter is 0.9mm. |
| Pull Cord | Shall braided polyester and of sufficient length to control raising and lowering of shade. Outside diameter is 1.8mm. |
| Tassel | 100% PVC. Shall comply with all safety requirements. |
| Stop Ball | 100% PVC. Shall comply with all safety requirements. |
| Installation Brackets: | Constructed of cold rolled steel. Zinc plated. Intermediate brackets spaced no wider than 36” apart. |
| Sizes | Outside mounted window coverings will be made to exact ordered measurements. Inside mounted horizontal shades will have 1/2” deducted at the factory from width. See Product Limits. |
PRODUCT LIMITS
| Controls (Manual) | Min. Width | Max. Width | Min. Drop | *Max. Drop |
|---|---|---|---|---|
| Standard | 12" | 72" | 5" | 72" |
Maximum Sq. Footage *36 sq. ft. under warranty
*Exceptions available upon request
standard
PRODUCT SPECIFICATIONS
| Fabric | Translucent or Room Darkening spun lace, non woven fabric. 100% Polyester |
| Head Rail | 1 1/2” high x 1 3/4” deep extruded aluminum with PVC end caps. Depth with installation bracket is 2”. |
| Slat Insert | Cold rolled spring tempered virgin aluminum slat. To have normal width of 1” and be 0.006” thickness after paint. Valance to be finished with a polyester baked enamel. Color coordinated to match the fabric. |
| Bottom Rail | 1/2” High x 1 5/8” deep extruded aluminum with PVC end caps. |
| Cord Lock | Cord lock shall be secured to the head rail channel. Lock body shall be constructed of clear polycarbonate,. Floating gear and pins locks shall e made of brass. Cord lock to be of crash-proof design. |
| Cord Cleat | Cleat is made of clear 100% PVC. |
| Lift Cords | Shall be braided polyester and of sufficient length to control the raising and lowering of the shade. Outside diameter is 0.9mm. |
| Tassel | 100% PVC. Shall comply with all safety requirements. |
| Stop Ball | 100% PVC. Shall comply with all safety requirements. |
| Installation Brackets: | Constructed of cold rolled steel. Zinc plated. Intermediate brackets spaced no wider than 36” apart. |
| Sizes | Outside mounted window coverings will be made to exact ordered measurements. Inside mounted horizontal shades will have 1/2” deducted at the factory from width. See Product Limits. |
PRODUCT LIMITS
| Controls (Manual) | Min. Width | Max. Width | Min. Drop | *Max. Drop |
|---|---|---|---|---|
| Standard | 7" | 144" | 5" | 144" |
Maximum Sq. Footage *144 sq. ft. under warranty
*Exceptions available upon request
cordless top-down/bottom-up
PRODUCT SPECIFICATIONS
| Fabric | Translucent or Room Darkening spun lace, non woven fabric. 100% Polyester. |
| Top Head Rail | 1 1/2” High x 1 3/4” Deep extruded aluminum, with PVC end caps. Depth with installation bracket is 2”. |
| Mid Head Rail | 3/4” high x 1 5/8” deep extruded aluminum with PVC end caps. |
| Bottom Rail | 1/2” High x 1 5/8” deep extruded aluminum with PVC end caps. |
| Cordless Modules | Cordless modules are constructed with clear PVC body. Lift cord is wound inside the module. Steel spring provides tension to pull the shade up. A steel d-rod link all modules together inside the head rail. |
| Lift Cord | Shall be braided polyester and of sufficient length to control the raising and lowering of the shade. Outside diameter is 0.9mm. |
| Weights | 100% Steel, Zinc plated with double sided tape. |
| Handle | 100% PVC |
| Installation Brackets: | Constructed of cold rolled steel. Zinc plated. Hex head screws are included. Intermediate brackets spaced no wider than 36” apart. |
| Sizes | Outside mounted window coverings will be made to exact ordered measurements. Inside mounted horizontal shades will have 1/2” deducted at the factory from width. See Product Limits. |
PRODUCT LIMITS
| Controls (Manual) | Min. Width | Max. Width | Min. Drop | *Max. Drop |
|---|---|---|---|---|
| Cordless | 19" | 84" | 5" | 72" |
Maximum Sq. Footage *42 sq. ft. under warranty
*Exceptions available upon request
